M92 is a modular, demountable partition system based on hidden profiling in galvanised steel, perfect when it comes to transforming new or renovated areas into ideal environments for communication and concentration.
With a wide range of finishes and layouts, M92 stands out for being truly flexible and easy to reuse. It is complemented with a wall cover system.
The panels hang from a Z-profile system and are separated from each other by a 10-mm groove. The bottom-runner is partially hidden, which considerably alleviates the visual weight. The door and window frames are independent from the internal structure in order to simplify assembly and dismantling, and the glass panes are demounted using perimeter glass stops. The system can cater for uneven heights of +-20mm. M92 has optimum sound insulation, 41.3 dB on blind modules (A)- (Applus-España, per EN 74040).
The M92 Fuga system caters for blind or glazed, made-tomeasure, horizontal modules. Like the rest of the range, M92 Fuga is available in our full range of finishes, is totally versatile, easy to assemble and maintain, and all the materials and components the system employs are reusable.
In order to achieve the perfect aesthetic integration of all spatial elements, the programme includes the D92 cover system for walls and columns. Its telescopic system is capable of absorbing uneven wall surfaces.
M92/11 rounds off the original programme with its modified structural components, redesigned to lighten up the appearance they initially lent to the partition assembly.
The top- and bottom-runners are the same as each other and significantly less high at 20 mm as opposed to the 60 mm of the original format. This change lends a new air to M92 and converts the system into a much more versatile solution.
M92/11 with metal surface finish was developed due to the need of some installations to increase acoustic insulation and significantly enhance fire resistance. This version of M92/11 includes a new clipping system that caters for butt-jointed panels. The result in terms of aesthetics is clear, the original 10-mm groove disappearing and joints between modules being hardly noticeable.
M92/11 & QUO
Finally, if you are looking for a simple, more economical solution to partition your office, M92/11 can be used in conjunction with Quo partitioning. Quo is Dynamobel’s most basic partition. It is only available in glazed modules. Through a set of assemblies, Quo can be used together with M92/11 and 1:10, programmes which provide a wider product range and whose specifications are very different.
